VC-60B+ İzolasyon Test Cihazı
-
VC60B+ Insulation Resistance Tester, Alarm for High voltage, Audible & Visual Alarm for short circuit, AC voltage, Resistance, Continuity tests. VC60B+ insulation tester, with safety protection high voltage warning, insulation breakdown short circuit alarm, continuous insulation test device for specific environment, accurate and safe for you to use with peace of mind. It can test theinsulation resistance between various generators, motors, power sockets, cables, enameled coils, conductors and non-conductorson trains, EMUs, and equipment. 2000 digits display
153.12.01.10
|
Technical Data: |
|
|
|
|
|
Basic function |
Range |
Accuracy |
Resolution |
|
|
Insulation Resistance |
250V±10% test voltage |
0~200MΩ |
±(4.0%+2) |
100kΩ |
|
|
500V±10% test voltage |
0~200MΩ |
|
100kΩ |
|
|
1000V±10% test voltage |
0~2GΩ |
|
1MΩ |
|
Resistance |
|
0~2kΩ |
±(1.0%+5) |
1Ω |
|
DCV |
|
0~1000V |
|
1V |
|
ACV |
|
0~750V |
±(1.5%+5) |
1V |
|
|
|
|
|
|
|
Special Function: |
|
|
|
|
|
Model |
VC60B+ |
|
|
|
|
Continuity alarm |
Less than 30Ω±10Ω |
|
|
|
|
Low battery indication |
Less than approx.7.5V |
|
|
|
|
Data hold |
√ |
|
|
|
|
LCD backlight |
Approx.10Sec. |
|
|
|
|
Function protection |
√ |
|
|
|
|
Input impedance |
1MΩ |
|
|
|
|
Sampling rate |
3 times/Sec. |
|
|
|
|
AC frequencyresponse |
50-200Hz |
|
|
|
|
Operation mode |
Manual range |
|
|
|
|
Max. display |
1999 |
|
|
|
|
LCD size |
75 x 52mm |
|
|
|
|
Power source |
1.5V AA battery x6pcs, or external DC 9V powersource |
|
|
|
|
Power consumption |
Quiescent current approx.3mA |
|
|
|
Industrial areas
Emitter
Receiver
RJ11 Connector Clip Line
RJ45 Connector Cable
Earphone
Cloth Bag
User Manual
Color Box
9V Batteries
– Garanti süresi, malın teslim tarihinden itibaren başlar ve garanti süresi 2 yıldır.
VC60B+ Insulation Resistance Tester, Alarm for High voltage, Audible & Visual Alarm for short circuit, AC voltage, Resistance, Continuity tests. VC60B+ insulation tester, with safety protection high voltage warning, insulation breakdown short circuit alarm, continuous insulation test device for specific environment, accurate and safe for you to use with peace of mind. It can test theinsulation resistance between various generators, motors, power sockets, cables, enameled coils, conductors and non-conductorson trains, EMUs, and equipment. 2000 digits display
